P. 61
Order Picker
แบบกระบะหลัังคอกเตี้้�ย With Tubular Cage
ิ
ั
• คอกกระบะสููง 100 มม. เชื่่�อมติิดกับฐานกระบะทั้�ง 4 ด้าน เพิ่�มความแข็็งแรง
1140
100
b1
h4
755
h7 655
m2
EV-500-T80 y I5
I1
Type of Rear Compartment With Backrest and Side Cage With Tubular Cage
Model EV-500-B80 EV-500-B38 EV-500-T80 EV-500-T38
Code A310109001 A310109002 A310109003 A310109004
Load Capacity (kg) 500 500
Wheelbase y (mm) 920 920
Service Weight including Battery (kg) 178 155 173 150
Axle Loadings Unladen Front/Rear (kg) 60/120 51/102 58/116 50/100
Wheel Type-Front/Rear Elastic Rubber Foam/Solid Rubber Elastic Rubber Foam/Solid Rubber
Wheel Size-Front (mm) Ø 200x63 Ø 200x63
Wheel Size-Rear (mm) Ø 250 (3.00-4) Ø 250 (3.00-4)
Wheel-Number Front/Rear
(X = Drive Wheel) 1/2X 1/2X
Overall Dimension l1xb1xh4 (mm) 1350x590x1200 1350x590x1200
Standing Platform Height h7 (mm) 150 150
Rear Overhang l5 (mm) 225 225
Ground Clearance at Centre of Wheelbase m2 (mm) 80 80
Turning Radius (mm) 1500 1500
Travel Speed, Laden/Unladen (km/h) 4/5 4/5
Gradeability, Laden/Unladen (%) 6/12 6/12
Continuous Operation @ Max Load (hr) 4.5 2.5 4.5 2.5
Brakes Electromagnetic Electromagnetic
Drive Motor (w) 450 (DC) 450 (DC)
Deep Cycle Deep Cycle
Battery Type Deep Cycle Deep Cycle
(Free Maintenance) (Free Maintenance)
Battery Voltage/Capacity 5 Hours Rate (V/Ah) 24 (12Vx2)/80 24 (12Vx2)/38 24 (12Vx2)/80 24 (12Vx2)/38
Charger Type External External
Charger Voltage/Current (V/Ah) 24/15 24/10 24/15 24/10
Price/Unit* (฿) 124,000.- 119,000.- 121,500.- 117,500.-
*ราคารวมแบติเติอร่�และติู้ชื่าร์จ
สอบถามราคาเพิ่�มเติม 02-096-9999 (200 ค่�สาย) [email protected] 61
่
่
